Description
Specifications
| Flow | Head | Power |
|---|---|---|
| 0.2 / 2.6 | 0.4 / 6 | 0.01 / 0.045 |
| mc / h | m | kW |
Operating Conditions
- Liquid temperature range: +5 °C to +65 °C
- Ambient temperature range: 0 °C to +40 °C
- Maximum allowable working pressure: 3 bar
- Storage conditions: –10 °C to +50 °C, up to 95% relative humidity at 40 °C
- Certifications: Compliant with CE requirements
- Sound pressure level: ≤ 45 dB(A)
- Minimum suction pressure: –0.05 bar at 75 °C and 0.28 bar at 90 °C
- EMC standards: EN 55014-1, EN 55014-2, EN 61000-3-2, EN 61000-3-3
- Connections: ISO 228 threaded ports, G 1
